Caribbean Sailing Yachts, known as CSYs, are heavy-displacement recreational sailboats built during the 1970s and 1980s in Tampa, Florida. CSY went out of business in the early 1980s; however, the well-founded boats have continued to sail the world's oceans for the past two decades. CSY's unique script logo was imprinted on a brass companionway medallion, dishware, and trailerboard design.
Insert images when approved of trailerboards, and dishes. The CSY boats were sold directly from the factory, without any dealerships or middle-men. Two books were published showing all stages of construction. These books, entitled "CSY Guide to Buying a Yacht", were used as the primary means of promotion. One 168-page soft-cover book was published in 1977. A shorter 138-page version was republished in 1979. Additionally CSY used a film strip, plant tours, boat shows and trial sails as sales tools. CSY also published a 38-page soft-cover "CSY Charter Manual."[JPEG Images to be added here when approved197 Book, 1979 book, chartering manual.
Maps, Directions, and Place Reviews
Introduction
Caribbean Sailing Yachts Corporation (CSY) began as a charter company operating in the Caribbean. They were the first company to come up with the concept of charter ownership, pioneered by CSY founder and owner Dr. John Van Ost, a New Jersey dentist with a love of sailing. CSY developed and perfected the 'charter lease back' program. In this program, an individual purchased the yacht and subsequently placed it into the charter fleet to cover the cost of the initial payments. Prior to the end of CSY, Dr. Van Ost envisioned the time share concept. He aimed to build the Corsair 81 mega yacht (mega in its day). These yachts were going to be available to multiple people to rent with crew. CSY originally purchased boats from companies such as Irwin. However, chartering demanded stronger boats to withstand bare-boat charter with less experienced captains and crew. CSY went into the boat manufacturing business, working initially with Ted Irwin, a well-known and successful designer of affordable cruising and racing sailboats in the Tampa. Irwin heavily influenced the CSY 44 hull design. From 1975 to 1980 CSY built boats of between 33 and 44 feet (13 m). They were similar in their appearance and hull shape. The 44-foot (13 m) designs feature a raised aft deck allowing for a large aft stateroom. CSY boats were built to unusually high standards of strength, durability, and quality consistent with Lloyd's design and boat building requirements. Insert images of the late Van Ost and Schmidt
Although many of these new boats were purchased outright by their new owners, most, particularly the 44 walk-over model, were sold under an agreement that the boat would be in charter, run by the CSY Charter Company for a number of years, after which the boat would be paid off and revert to the "original purchaser". This system is a typical arrangement with many boats under charter even today. It is known as the "charter lease back" and is used by such companies as the Moorings and Sunsail.
CSY 44's were built with either a deep or shallow draft. Deep-draft models were designed so that their draft could be modified and permanently changed to shoal draft. This enabled the same boat to initially be used as a deep-draft vessel in the Caribbean under charter, and then returned to their owner who could then make the draft modification so the boat could be cruised on the East Coast, the shallow Florida Keys, or the Bahamas.
CSY developed several models including a 33, two layouts of a 37, the popular 44' "Walkover", a 44' "Walk Through", a 44' pilothouse, and even a special purpose sailing / fishing vessel known as the Bottomliner.
Tampa Yacht Rentals Video
Construction
The CSY line was well designed. Features like a built-in full-size trash receptacle in the galley, large refrigeration boxes (3 boxes totaling 21 cubic feet (0.59 m3) on the CSY 44 WO), and a larger-than-king-size bed in the aft master cabin (CSY 44) made the boat comfortable in port as well as a good sea boat.
CSY did not use wood lamination in its construction, a technique that is the curse of many boats of this vintage. The CSY hull is up to 1.5" of solid fiberglass reinforced plastic resin with 14 dual layers (one sheet of fiberglass mat and one sheet of fiberglass weave = one layer). The avoidance of wood cores extends to the deck, which is also solid fiberglass. The only wood used in the construction of these boats are heavy laminated structural stringers, bulkheads and interior furniture.
CSY Models
CSY developed a full line of sailboats: the 33, the 37, and the 44, initially in two configurations: the "walk-over", and the pilothouse. Most of the 44's built were walk-overs, with a very spacious cockpit and separate, unconnected staterooms forward and aft. Only much later, did CSY build the 44 "walk-through" model, and only about 40 of these were built, before CSY went out of business.
CSY 44
Walk Over 44
This model is referred to as "walk-over" because one has to walk up to the cockpit from the main salon and then down to the separate aft cabin.
The CSY 44 WO is typically what one thinks of when someone mentions a CSY. This is due to its use as a charter boat in the Caribbean in the late 1970s and early 1980s.
Walk Through 44
About 41 of these were built, with the last boat being number 42, completed outside the yard.
The CSY 44 Walk Throughs were built late in the production run and are sought after boats, mainly because of their walk-through configuration. While this design sacrifices some cockpit space in order to add the below-decks walkway from the main salon to the aft master stateroom, it is seen by many as a fair trade. It has a comfortable, conventional cockpit with ample room for guest visiting. There are two longitudinal bench seats long enough for sleeping and an ample bench seat aft of the central binnacle. Other layout differences from the Walk Over include a stand-up engine room with workbench to port, a main cabin navigation station/table to port, the galley with side-loading refrigerator/freezer aft located in the starboard passageway leading aft, and all-oak instead of teak interiors. Many of these boats were outfitted with a large fiberglass box on the stern deck suitable for fuel and gas storage. The after section of the main cabin coach roof is raised, adding headroom below and increasing visibility through four large windows.
Many Walk Throughs were delivered with shoal draft and tall mast. The normal rig configuration was a cutter, with a few rigged as cutters/ketches. All of the WT masts were in the cutter position, and if a ketch, a mizzen would be added onto the aft deck with the boom extending far astern.
CSY 44 Pilothouse
This version of the CSY was delivered as a true Ketch which has the main mast moved forward 4 feet (1.2 m) from the cutter position of the other rigs. This true ketch rig was the only rig available on the Pilothouse 44. No staysail.
CSY 44 Bottomliner
Only 6 of the Bottom Line 44's were actually built, of the six boats that were built, only 5 actually saw service and were used in the CSY sponsored fishing school. The boats were sold to investors who then leased them back to CSY for use in the commercial fishing school. At the time one of the inducements to attend the fishing school was that if a student went through the school and then Captained one of the vessels for 5 years the Captain would then be eligible to buy the vessel at salvage value. This model was a CSY 44 hull and rigging modified to be a bottom fishing vessel. The idea was the owner/fisherman could use the sail to help defer the cost of fuel when fishing. The original idea of the vessel was to have a large fish hold centered in the boat, with a crew compartment forward and a Captains quarters aft and work center in the tall pilothouse. This commercial pilothouse provides a good visible with navigation counter, resting berth, and galley--sliding doors either side. A shaded area was built over the fish hold; side decks are continuous, with no steps or raised section aft.
The CSY Bottomliner was an excellent fishing platform for the grouper snapper fishery, it would fish in much heavier seas and at much greater depths than the standard vessels of the time. It was rigged with six large commercial bottom fishing reels called "bandits", for use in the Grouper/Snapper fishery. The vessels had all the very latest electronics of the time dual marine FM radios plus a single side band radio for long distance over the horizon communication. It also had multiple fish finding equipment, a whiteline recorder plus a color video recorder. The Bottomliner also had the latest in navigation with LORAN C which would allow getting back to productive spots within about 100'. The boats were also equipped with radar as an aid to navigation.
The ice hold was equipped with large eutectic refrigeration plates that allowed ice to be easily kept in the 5 large bins on either side of the center line of the vessel for standard 10-day fishing trips. The hold also had a large freezer for storage of bait. This arrangement of ice and refrigeration only required running the diesel for approximately 2 hours a day to maintain temps in the hold, further saving on fuel and ice costs. Typically only about 3 tons of ice was need for a 10-day trip as opposed to the 6 to 10 tons that a standard vessel typically required. Fuel was a major cost factor for the standard grouper snapper vessels, the standard diesel driven vessels of the time could use as much as 500 to 1000 gallons on a ten-day trip where as the CSY typically used about 50 gallons and rarely used more than 100 gallons of its 500-gallon tankage. This pushed the break even point down substantially and increase profits proportionately.
Unfortunately these six wonderful fishing vessels were caught up in CSY's demise in 1981 remained tied up to the docks in St. Petersburg for an extended period of time suffering neglect and deterioration. I am told that one was so neglected that it sunk at the dock.
Cygnet 44
During the fifth year of manufacturing the CSY 44 in its various versions, the CSY Yacht Corporation came out with a new concept to reduce the cost of the yachts. This new version was marketed as the CYGNET 44 line. Shortly thereafter, the CSY Yacht Corporation went out of business. This must have happened in 1981. The CYGNET 44 WT was introduced at the Fort Lauderdale Boat Show in 1980. The Cygnet did not have the trademark CSY hull ports on its bow.
CSY 37
The CSY 37 is an aft cockpit model with a roomy interior. The CSY 37 was built to the same high standards of construction as the CSY 44.
CSY 33
The CSY 33, designed by P. Schmitt, was the smallest CSY hull put into production. Like all CSYs it is a sturdily built boat that exhibits many of the CSY distinctive touches such as the scroll work on the bow. The CSY 33 was produced from 1979 to 1982. The 33 had a 'pilothouse-style' main saloon, but did not have an inside steering station.
Gulfstar CSY 50
This boat is often confused with the other CSYs on the market; however, it has no relationship to the Caribbean Sailing Yachts or the CSY company.
CSY history
Caribbean Sailing Yachts, Ltd. was unable to find a manufacturer who would build sailing yachts to the high standards it required for its charter service; therefore, C.S.Y. Yacht Corporation was founded by Caribbean Sailing Yachts, Ltd.'s chief executive officer, John R. Van Ost, on September 1, 1976.
At the start in 1976, a new plug and mold was built, and the first boat went into the water on January 15, 1977. Production gradually increased to seven CSY-44's per month by May, 1977.
Along the way, another version of the CSY-44 was designed and built. The CSY-44 Pilot House Ketch was introduced at the fall boat shows.
A CSY-37 was designed, built, and shown for the first time at the Miami Boat Show in 1978. The CSY-37 yacht was subsequently redesigned into two models, the two stateroom model, and the one stateroom model.
In the fall of 1978, the CSY-33 was introduced at Annapolis.
Fate
Many ask "if they made such a good boat what happened to them?" CSY was a victim of building their boats too well! They went broke because the cost of the boats was too high for the price being asked. Some say this was due to their view of the business. Apparently they viewed boat production simply as a means to supply their charter fleet in the Caribbean. Unfortunately CSY was not able to maintain this business model. Since their main customer was lease back for their charter business, the closing of tax loopholes most likely contributed to or accelerated their demise.
Antigua Yachts, under the ownership of John Coats, purchased the CSY molds and boats in progress and started building the CSY 44 again, under the new name of Antigua 44. It is said that 20-30 of these highly customized versions of the CSY 44 walk-through were built in the 80's. Often these boats had teak interiors versus the white oak or Formica interiors of the earlier CSYs. Antigua only made few of these boats before going out of business, thus ending the CSY line of sailing yachts.
Source of the article : Wikipedia
